Product Specs
Dimensions
- Maximum Digging Depth
- 117 in
- Operating Weight
- 2326 lb
- Overall Length
- 87 in
- Stabilizer Spread - Operating Position
- 71.4 in
- Digging Depth at 610 mm (2 ft)
- 124.3 in
- Digging Depth at 4220 mm (8 ft)
- 106.5 in
- Straight Wall Digging Depth
- 79.5 in
- Overall Operating Height
- 146.6 in
- Loading Height
- 97.2 in
- Loading Reach
- 73.6 in
- Reach From Swing Pivot at Ground Line
- 158.6 in
- Swing Arc
- 180 degrees
- Bucket Rotation
- 183 degrees
- Bucket Breakout Force
- 7012.9 lb
- Stick Breakout Force
- 3538.4 lb
- Boom Pivot Height
- 17.6 in
- Ground Clearance
- 3.9 in
- Transport Height
- 100.9 in
- Transport Width
- 80.4 in
- Required Hydraulics
- Standard Flow
- Optimal Hydraulic Pressure
- 180-230 bar (2600-3340 psi)
- Total Side Shift Travel
- 33 in
- Interface Type
- Skid Steer Coupler
