Product Specs
Engine
- Engine Model
- Cat® C15
- Rated Speed
- 1800 r/min
- Net Power - SAE J1349:2011
- 405 hp
- Net Power – ISO 9249:2007
- 405 hp
- Engine Power - ISO 14396:2002
- 426 hp
- Gross Power - SAE J1995:2014
- 434 hp
- Peak Net Torque (1,300 rpm)
- 1479 lbf·ft
- Torque Rise
- 33%
- Maximum Altitude without Derating (U.S. EPA Tier 4 Final/EU Stage V)
- 9298 ft
- Maximum Altitude without Derating (U.S. EPA Tier 3/EU Stage IIIA)
- 9098 ft
- Bore
- 5.4 in
- Stroke
- 6.7 in
- Displacement
- 927.6 in³
- High Idle Speed
- 2300 r/min
- Low Idle Speed
- 800 r/min
- Note (1)
- Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator.
- Note (2)
- Two engine emission configurations are available. One meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, and Japan 2014 emissions standards. The other meets Brazil MAR-1 emission standards, emitting equivalent to U.S. EPA Tier 3 and EU Stage IIIA.
Operating Specifications
- Operating Weight – Straight Blade (Tier 4 Final/Stage V)
- 74966 lb
Transmission
- Transmission Type
- Cat planetary - powershift - ECPC
- Forward - 1
- 3.8 mile/h
- Forward - 2
- 6.9 mile/h
- Forward - 3
- 12.2 mile/h
- Forward - 4
- 21.6 mile/h
- Reverse - 1
- 4.3 mile/h
- Reverse - 2
- 7.8 mile/h
- Reverse - 3
- 13.9 mile/h
- Reverse - 4
- 24.7 mile/h
Hydraulic System - Lift/Tilt
- Pump Flow at 1,800 rpm
- 30.9 gal/min
- Main Relief Pressure
- 3771 psi
- Maximum Supply Pressure
- 3495 psi
- Cylinders, Double Acting - Lift, Bore and Stroke
- 120 mm × 1070 mm (4.7 in × 42.1 in)
- Cylinder, Double Acting - Tilt and Tip, Bore and Stroke
- 140 mm × 230 mm (5.5 in × 9.1 in)
Hydraulic System - Steering
- Steering System - Circuit
- Pilot operated, load sensing
- Bore
- 4.5 in
- Stroke
- 22.7 in
- Steering System - Pump
- Variable displacement piston
- Max Flow at 1,800 rpm
- 44.9 gal/min
- Relief Valve Setting - Steering
- 3481 psi
- Vehicle Articulation Angle
- 86°
Service Refill Capacities
- Cooling System
- 30.6 gal (US)
- Engine Crankcase
- 9 gal (US)
- Transmission
- 17.4 gal (US)
- Fuel Tank
- 206.6 gal (US)
- Diesel Exhaust Fluid Tank (For Tier 4 Final/Stage V Only)
- 8.5 gal (US)
- Differential - Final Drives - Front
- 26.4 gal (US)
- Differential - Final Drives - Rear
- 29.1 gal (US)
- Hydraulic Tank Only
- 35.4 gal (US)
- Hydraulic System - Implement/Steering
- 56.5 gal (US)
- Note (1)
- All nonroad Tier 4 Final, EU Stage V, and Japan 2014 (Tier 4 Final) diesel engines are required to use:– Ultra low sulfur diesel (ULSD) fuels containing 15 ppm (mg/kg) sulfur or less.– Cat engines are compatible with the following renewable, alternati
Air Conditioning System
- Air Conditioning
- The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. - If equipped with R134a (Global Warming Potential = 1430), the system co
Axles
- Front
- Planetary – Fixed
- Rear
- Planetary – Oscillating
- Oscillation Angle
- ±11°
Braking System
- Parking Brake
- Drum and shoe, spring applied, hydraulic released
- Brakes
- Multi-disc wet (enclosed) 4 WHL
Sound Performance - Standard
- Operator Sound Level (ISO 6396:2008)
- 73 dB(A)
- Machine Sound Level (ISO 6395:2008)
- 113 dB(A)
Sound Performance - Suppression
- Operator Sound Level (ISO 6396:2008)
- 72 dB(A)
- Machine Sound Level (ISO 6395:2008)
- 110 dB(A)
Dimensions (Approximate)
- Height to Top of Beacon
- 14.5 ft
- Height - Top of Exhaust Stack
- 14.2 ft
- Height - Top of Hood
- 10.5 ft
- Ground Clearance - Bumper
- 2.8 ft
- Centerline of Rear Axle to Edge of Bumper
- 9.28 ft
- Centerline of Front Axle to Hitch
- 6.1 ft
- Wheel Base
- 12.1 ft
- Length - With Blade on Ground - Straight Blade
- 27.6 ft
- Ground Clearance to Trunnion
- 1.45 ft
- Height - Top of Cab
- 13.5 ft
- Width Over Guardrails
- 10.94 ft
- Ground Clearance
- 1.8 ft
Standard Equipment
-
- Note
-
- Standard and optional equipment may vary. Consult your Cat dealer for details.
-
- Safety
-
- Camera, rear vision
- Alarm, back-up
- Light, warning switched (LED strobe)
- Lighting, access stairway
- Cat Detect: Object Detection (ready)
- Mirror, internal (panoramic)
- Mirrors, rearview (externally mounted)
- Seat belt with minder, retractable, 76 mm (3 in) wide
- STIC control system with lockout
- Emergency platform egress
- Stairway, left and right rear access
- Toe kicks
-
- Efficiency
-
- Hydraulically driven demand fan
-
- Power Train
-
- Air to air aftercooler
- Auto shift
- Brakes, full hydraulic, enclosed, wet multiple disc service brakes
- Cat clean emission module (Tier 4 Final/Stage V)
- Electro-hydraulic parking brake
- Electronic Clutch Pressure Control (ECPC)
- Engine, Cat C15 emitting equivalent to Tier 3/Stage IIIA or meets Tier 4 Final/Stage V emission standards
- Fuel priming pump (electric)
- Fuel to air cooler
- Integrated braking system
- Muffler (under hood) (Tier 3/Stage IIIA)
- Radiator, Aluminum Modular (AMR)
- Separated cooling system
- Single Clutch Speed Shifting (SCSS)
- Throttle lock
- Torque converter with Lock Up Clutch (LUC)
- Transmission, planetary, with (4F/4R) speed range control
-
- Cold Weather
-
- Starting aid (ether) automatic
- Antifreeze, premixed 50% concentration extended life (–34° C/–29° F)
-
- Electrical
-
- Alternator, 150 amp
- Batteries, maintenance-free (4 – 1,000 CCA)
- Electrical system, 24V
- Lighting system, halogen (front and rear)
- Lights, directional (rear)
- Starter, electric (heavy duty)
-
- Operator Environment
-
- Radio, CB (ready)
- 12V power port for mobile phone or laptop connection
- Air conditioner
- Cab, sound-suppressed pressurized, internal four-post rollover protective structure/ falling objects protective structure (ROPS/ FOPS), radio ready for entertainment includes antenna, speakers, converter (12-volt 10/15-amp), and power port
- Cab door, sliding window (LH)
- Coat and hard hat hooks
- Electro-hydraulic tilt and tip controls
- Fingertip shifting controls
- Flip-up armrest
- Heater and defroster
- Horn, electric
- Implement hydraulic lockout
- Instrumentation, gauges: – DEF fluid level (Tier 4 Final/Stage V) – Engine coolant temperature – Fuel level – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature
- Instrumentation, warning indicators: – Action alert system, three categories – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp – Parking brake status
- Cab precleaner, powered
- Light, (dome) cab
- Lunch box and beverage holders
- Seat, premium plus containing forced air heating and cooling, two-way thigh adjustment, power lumbar and back bolster adjustment, ride stiffness adjustment, dynamic end dampening, and leather finish
- Sun visor, front
- Rubber mounted, laminated, tinted glass
- Transmission gear (indicator)
- Vital Information Management System (VIMS): – Graphical information display – External data port – Customizable operator profiles
- Wet-arm wipers/washers (front and rear): – Intermittent wipers (front and rear)
-
- Other
-
- Guard, driveshaft
- Guards, crankcase and power train
- Fold down exhaust stack for shipping
- Fuel tank, 782 L (207 gal)
- Hitch, drawbar with pin
- Hoses, Cat XT™
- Hydraulic, engine, and transmission oil coolers
- Vandalism protection caplocks
- Venturi stack
-
- Service
-
- Ground level engine shutoff
- Ground level lockable master disconnect switch
- Auxiliary start receptacle
- Doors, service access (locking)
- Ecology drains for engine, radiator, transmission, hydraulic tank
- Engine, crankcase, 500 hour interval with CJ-4 oil
- Engine precleaner
- Fire suppression ready
- Oil change system, high speed
- Oil sampling valves
- Product Link
- Lighting underhood
- Total hydraulic filtration system
Attachments
-
- Note
-
- Standard and optional equipment may vary. Consult your Cat dealer for details.
-
- Operator Environment
-
- Radio, AM/FM/AUX/USB/Bluetooth®
-
- Other
-
- Counterweight, Front
-
- Sound
-
- Sound Suppression
-
- Electrical
-
- Lighting system, LED
-
- Service
-
- Tire Pressure Monitoring System
- Dual stage engine precleaner
-
- Cold Weather
-
- Heater, engine coolant, 120V
- Heater, engine coolant, 240V
- Antifreeze, –50° C (–58° F)
- Arctic hydraulic oil
- Mirrors, heated
-
- Power Train
-
- No-spin rear axle
