Product Specs
Engine
- Net Power - ISO 9249
- 117 hp
- Engine Model
- C4.4
- Engine Power - ISO 14396
- 122 hp
- Bore
- 4.13 in
- Stroke
- 5 in
- Displacement
- 269 in³
Weights
- Operating Weight
- 42340 lb
Working Ranges & Forces
- Maximum Digging Depth
- 20 ft
- Boom
- Reach 5.1 m (16'9")
- Stick
- R2.9 m (9'6")
- Bucket
- .91 m³ (1.19 yd³)
- Maximum Reach at Ground Level
- 28.83 ft
- Maximum Cutting Height
- 29.25 ft
- Maximum Loading Height
- 20.58 ft
- Minimum Loading Height
- 7.42 ft
- Maximum Depth Cut for 2440 mm (8 ft) Level Bottom
- 20.1 ft
- Maximum Vertical Wall Digging Depth
- 16.17 ft
- Bucket Digging Force - ISO
- 27651 lbf
- Stick Digging Force - ISO
- 17984 lbf
Hydraulic System
- Main System - Maximum Flow
- 300 l/min (79 gal/min)
- Maximum Pressure - Equipment
- 5076 psi
- Maximum Pressure - Swing
- 3626 psi
- Maximum Pressure - Travel
- 5076 psi
Swing Mechanism
- Swing Speed
- 8.5 r/min
- Maximum Swing Torque
- 37394 ft·lbf
Service Refill Capacities
- Fuel Tank Capacity
- 76.61 gal (US)
- Cooling System
- 6.9 gal (US)
- Engine Oil
- 3.57 gal (US)
- Swing Drive
- 2.11 gal (US)
- Final Drive - Each
- 2.11 gal (US)
- Hydraulic System - Including Tank
- 31.96 gal (US)
- Hydraulic Tank
- 28 gal (US)
- DEF Tank
- 5.4 gal (US)
Dimensions
- Boom
- Reach 5.1 m (16'9")
- Stick
- R2.9 m (9'6")
- Bucket
- .91 m³ (1.19 yd³)
- Shipping Height - Top of Cab
- 10.17 ft
- Shipping Length
- 28.17 ft
- Tail Swing Radius
- 8.25 ft
- Counterweight Clearance
- 3.33 ft
- Ground Clearance
- 1.42 ft
- Track Length
- 13.33 ft
- Length to Center of Rollers
- 10.75 ft
- Track Gauge
- 6.5 ft
- Transport Width
- 8.83 ft
