Product Specs
Engine
- Engine Model
- C4.4 ACERT
- Net Flywheel Power
- 161 hp
- Bore
- 4.13 in
- Stroke
- 5 in
- Displacement
- 269 in³
- Engine RPM
- 1800 r/min
- Gross Power - SAE J1995:2014
- 164 hp
- Net Power - SAE J1349:2011
- 161 hp
Weights
- Operating Weight
- 49200 lb
Drive
- Maximum Drawbar Pull
- 46086 lbf
- Maximum Travel Speed
- 3.5 mile/h
Service Refill Capacities
- Fuel Tank Capacity
- 108 gal (US)
- Cooling System
- 7.9 gal (US)
- Engine Oil
- 6.6 gal (US)
- Swing Drive
- 2.1 gal (US)
- Final Drive - Each
- 2.1 gal (US)
- Hydraulic System - Including Tank
- 68.7 gal (US)
- Hydraulic Tank
- 42 gal (US)
- DEF Tank Capacity
- 5.5 gal (US)
Dimensions* - Reach Boom - 5.7 m (18'8)
- Tail Swing Radius
- 9.25 ft
- Track Length
- 14.67 ft
- Length - Center of Rollers
- 12 ft
- Handrail Height
- 9.92 ft
- Ground Clearance
- 1.5 ft
- Track Gauge
- 7.83 ft
- Shipping Height
- 10.25 ft
- Shipping Length
- 31.33 ft
- Counterweight Clearance
- 3.33 ft
- Note
- *With 1.19 m3 (1.56 yd3) HD Bucket
- Transport Width - 790 mm (31 in) Shoes
- 10.42 ft
Sound Performance
- ISO 6395 - Spectator Noise
- 99 dB(A)
- ISO 6396 - Operator Noise (Closed)
- 68 dB(A)
Working Ranges* - Reach Boom - 5.7 m (18'8)
- Maximum Vertical Wall Digging Depth
- 16.58 ft
- Minimum Loading Height
- 7.08 ft
- Maximum Loading Height
- 21.33 ft
- Maximum Digging Depth
- 22.08 ft
- Maximum Reach - Ground Line
- 32.33 ft
- Maximum Cutting Height
- 30.75 ft
- Maximum Depth Cut for 2440 mm (8 ft) Level Bottom
- 21.5 ft
- Note
- *With 1.19 m3 (1.56 yd3) HD Bucket
Machine Weight
- Operating Weight
- 49200 lb
- Note
- Long Undercarriage, Reach Boom, R2.9 (9'6") Stick, GD 1.19 m3 (1.56 yd3) Bucket and 790 mm (31") Triple Grouser Shoes.
Swing
- Swing Speed
- 11.2 r/min
- Swing Torque
- 45581 ft·lbf
Hydraulic System
- Maximum Pressure - Equipment - Heavy Lift
- 5511 psi
- Maximum Pressure - Equipment - Normal
- 5076 psi
- Main System - Maximum Flow - Total
- 113 gal/min
- Maximum Pressure - Travel
- 5076 psi
- Maximum Pressure - Swing
- 3626 psi
- Pilot System - Maximum Flow
- 6.4 gal/min
- Pilot System - Maximum Pressure
- 569 psi
