Product Specs
Weights
- Maximum Operating Weight
- 53911 lb
Operating Specifications
- Cutting/Mixing Width
- 96 in
- Maximum Cutting/Mixing Depth
- 20 in
- Maximum Travel Speed
- 6 mile/h
- Operating Speed
- 2.7 mile/h
- Rotor Options
- Universal, Combination, Spade
- Rotor Speed - First (at 2100 Engine rpm)
- 106 r/min
- Rotor Speed - Second (at 2100 Engine rpm)
- 144 r/min
- Rotor Speed - Third (at 2100 Engine rpm)
- 216 r/min
Engine
- Gross Power
- 350 HP
- Engine Model
- C11 with ACERT
Service Refill Capacities
- Fuel Tank Capacity
- 279 gal (US)
Dimensions
- Ground Clearance
- 28.3 in
- Length
- 32.83 ft
- Maximum Height
- 11.08 ft
- Wheel Base
- 20.75 ft
- Width
- 9.83 ft
Attachments
- Roll Over Protective Structure (ROPS)
- Falling Object Protective Structure (FOPS)
- Sliding Operator Station
- Sliding Cab
- Rear Wheel Drive
- Automatic Rotor Depth Control
- Four Mode Steering
- Hydraulically Operated Front Door
- Friction Torque Limiter
- Working Light Package
- Roading Light Package
- Warning Beacon Light
- Mirror Package
- Umbrella
- Water Spray System
- Powertrain Guard
- Universal Rotor
- Soil Rotor
