Product Specs
Ratings
- Power Range
- 503-567 bhp (375-423 bkW)
Engine
- Speed Range
- 2500 rpm
- Emissions
- IMO II
- Aspiration
- TA
- Bore
- 4.41 in
- Stroke
- 5.87 in
- Displacement
- 538 in³
- Rotation from Flywheel End
- Counterclockwise
- Configuration
- In-line 6, 4-Stroke-Cycle Diesel
Dimensions & Weights
- Approximate Engine Dry Weight
- 2086 lb
- Height
- 38.7 in
- Length
- 47.2 in
- Width - Engine
- 38.3 in
Standard Equipment
-
- Air Inlet System
-
- Aftercooler (sea water)
- Air Cleaner/Fumes Disposal (closed crankcase) - shipped loose
- Turbocharger
-
- Control Panels
-
- Electronic governor
- Hydraulic Electronic Unit Injection (HEUI) fuel system
- Electronic Control Module (ECM)
- Engine mounted 70-pin dedicated customer connector
- SAE J1939 data link
-
- Cooling System
-
- Thermostat and housing
- Jacket water pump, belt driven, centrifugal
- Auxiliary sea water pump, gear driven
- Expansion tank (heat exchanger engines only)
- Engine mounted heat exchanger, removable tube bundle (for sea water) (heat exchanger engines only)
- Engine oil cooler
- Auxiliary sea water lines
- Transmission oil cooler
-
- Flywheel & Flywheel Housings
-
- Flywheel, SAE No. 1, 113 teeth
- Flywheel housing, SAE No. 1
-
- Fuel System
-
- Fuel filter, RH service on Port, LH service on starboard
- Fuel transfer pump
- Fuel priming pump
-
- Lube System
-
- Crankcase breather
- Oil filter, front center service
- Oil filler, in valve cover
- Oil level gauge, RH service on port, LH service on starboard
- Oil pan
- Oil pan drain, RH service on port, LH service on starboard
- Engine oil pump (gear driven)
-
- Mounting System
-
- Front support, adjustable height
-
- Protection System
-
- Overspeed shutoff - electronic
-
- General
-
- Torsional vibration damper and guard
- Lifting eyes
- Literature
- Engine wiring
- RH or LH service options
Attachments
-
- Cooling System
-
- Coolant level sensor
-
- Exhaust System
-
- Exhaust Temp Sensor
- Watercooled Elbows
-
- Fuel System
-
- Fuel cooler
- Flexible fuel lines
-
- Instrumentation
-
- OEM Wiring Harness
- Engine to Engine Harness
- Wiring Harness
- Transmission Sensors
- Marine Power Display System
- Marine Power Display
- Marine Power Display Bracket
-
- Lube System
-
- Oil Filler
- Sump pumps, manual
- Sump pump lines
-
- Mounting System
-
- Vibration isolators
-
- Power Take-offs
-
- Crankshaft pulley
- Damper and Stub Shaft
- Pulley and Stub Shaft
-
- General
-
- Damper Guard
- Belt Guard - Alternator
-
- Packing
-
- Engine Protective Cover
- Export Packing
